1
1
2
2
-
-
6
6
2
2
9
9
5
5
0
0
1
1
X
X
2
2
C
C
h
h
a
a
n
n
n
n
e
e
l
l
M
M
o
o
d
d
u
u
l
l
e
e
R
R
e
e
p
p
l
l
a
a
c
c
e
e
m
m
e
e
n
n
t
t
• Remove the knob caps and retaining collars from the channel module to be replaced.
• Follow instructions #1 and #2 for the removal of the base plate and rear panel.
• Follow the instruction #11 for the removal of 629510X1 channel buscard.
• The faulty module will be attached to the buscard, fit the replacement assembly to the buscard and reassemble.
Appendix G - Service
130
Matrix Owner’s Manual
