31.6 ID codes and locking mechanism

There are several ID codes inside the STM32F10xxx MCUs. ST strongly recommends tools

designers to lock their debuggers using the MCU DEVICE ID code located in the external

PPB memory map at address 0xE0042000.

31.6.1 MCU device ID code

The STM32F10xxx MCUs integrate an MCU ID code. This ID identifies the ST MCU part-

number and the die revision. It is part of the DBG_MCU component and is mapped on the

external PPB bus (see Section 31.16 on page 1090). This code is accessible using the

JTAG debug port (4 to 5 pins) or the SW debug port (two pins) or by the user software. It is

even accessible while the MCU is under system reset.

DBGMCU_IDCODE

Address: 0xE004 2000

Only 32-bits access supported. Read-only.

31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16

REV_ID

rrrrrr r r r r rrrrrr

1514131211109876543210

Reserved

DEV_ID

rrrrrrrrrrrr
