DocID13902 Rev 15 494/1128

RM0008 Window watchdog (WWDG)

497

20.5 Debug mode

When the microcontroller enters debug mode (Cortex

-M3 core halted), the WWDG counter

either continues to work normally or stops, depending on DBG_WWDG_STOP

configuration bit in DBG module. For more details, refer to Section 31.16.2: Debug support

for timers, watchdog, bxCAN and I2C.

Table 98. Min-max timeout value @36 MHz (f

PCLK1

)

Prescaler WDGTB Min timeout value Max timeout value

1 0 113 µs 7.28 ms

2 1 227 µs 14.56 ms

4 2 455 µs 29.12 ms

8 3 910 µs 58.25 ms
