DocID13902 Rev 15 212/1128
RM0008 Interrupts and events
213
10.3.5 Software interrupt event register (EXTI_SWIER)
Address offset: 0x10
Reset value: 0x0000 0000
10.3.6 Pending register (EXTI_PR)
Address offset: 0x14
Reset value: undefined
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
SWIER
19
SWIER
18
SWIER
17
SWIER
16
rw rw rw rw
1514131211109 8 7654321 0
SWIER
15
SWIER
14
SWIER
13
SWIER
12
SWIER
11
SWIER
10
SWIER
9
SWIER
8
SWIER
7
SWIER
6
SWIER
5
SWIER
4
SWIER
3
SWIER
2
SWIER
1
SWIER
0
rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw rw
Bits 31:20 Reserved, must be kept at reset value (0).
Bits 19:0 SWIERx: Software interrupt on line x
If the interrupt is enabled on this line in the EXTI_IMR, writing a '1' to this bit when it is set to
'0' sets the corresponding pending bit in EXTI_PR resulting in an interrupt request
generation.
This bit is cleared by clearing the corresponding bit of EXTI_PR (by writing a 1 into the bit).
Note: Bit 19 used in connectivity line devices and is reserved otherwise.
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
Reserved
PR19 PR18 PR17 PR16
rc_w1 rc_w1 rc_w1 rc_w1
1514131211109 8 7654321 0
PR15 PR14 PR13 PR12 PR11 PR10 PR9 PR8 PR7 PR6 PR5 PR4 PR3 PR2 PR1 PR0
rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1 rc_w1
Bits 31:20 Reserved, must be kept at reset value (0).
Bits 19:0 PRx: Pending bit
0: No trigger request occurred
1: selected trigger request occurred
This bit is set when the selected edge event arrives on the external interrupt line. This bit is
cleared by writing a ‘1’ into the bit.
Note: Bit 19 is used in connectivity line devices only and is reserved otherwise.
