DocID13902 Rev 15 472/1128

RM0008 Basic timers (TIM6&TIM7)

472

17.4.9 TIM6&TIM7 register map

TIMx registers are mapped as 16-bit addressable registers as described in the table below:

Refer to Table 3 on page 51 for the register boundary addresses.

Table 94. TIM6&TIM7 register map and reset values

Offset Register

0x00

TIMx_CR1

Reserved

ARPE

Reserved

OPM

URS

UDIS

CEN

Reset value 00000

0x04

TIMx_CR2

Reserved

MMS[2:0]

Reserved

Reset value 000

0x08

Reserved

0x0C

TIMx_DIER

Reserved

UDE

Reserved

UIE

Reset value 00

0x10

TIMx_SR

Reserved

UIF

Reset value 0

0x14

TIMx_EGR

Reserved

Reset value 0

0x18

Reserved

0x1C

Reserved

0x20

Reserved

0x24

TIMx_CNT

Reserved

CNT[15:0]

Reset value 0000000000000000

0x28

TIMx_PSC

Reserved

PSC[15:0]

Reset value 0000000000000000

0x2C

TIMx_ARR

Reserved

ARR[15:0]

Reset value 0000000000000000
