RM0008 Advanced-control timers (TIM1&TIM8)

359

written after a COM event for the next step (this can be done in an interrupt subroutine

generated by the rising edge of OC2REF).

Figure 95 describes this example.

Figure 95. Example of hall sensor interface

counter (CNT)

TRGO=OC2REF

(CCR2)

OC1

OC1N

COM

Write CCxE, CCxNE

TIH1

TIH2

TIH3

CCR1

OC2

OC2N

OC3

OC3N

C7A3 C7A8 C794 C7A5 C7AB C796

and OCxM for next step

Interfacing timer

advanced-control timers (TIM1&TIM8)

ai17335
