Debug support (DBG) RM0008
1081/1128 DocID13902 Rev 15
Refer to the Cortex
®
-M3 r1p1 TRM for a detailed description of DPACC and APACC
registers.
The packet request is always followed by the turnaround time (default 1 bit) where neither
the host nor target drive the line.
The ACK Response must be followed by a turnaround time only if it is a READ transaction
or if a WAIT or FAULT acknowledge has been received.
The DATA transfer must be followed by a turnaround time only if it is a READ transaction.
31.8.3 SW-DP state machine (reset, idle states, ID code)
The State Machine of the SW-DP has an internal ID code which identifies the SW-DP. It
follows the JEP-106 standard. This ID code is the default ARM
®
one and is set to
0x1BA01477 (corresponding to Cortex
®
-M3 r1p1).
Table 222. Packet request (8-bits)
Bit Name Description
0 Start Must be “1”
1 APnDP
0: DP Access
1: AP Access
2RnW
0: Write Request
1: Read Request
4:3 A(3:2) Address field of the DP or AP registers (refer to Table 221)
5 Parity Single bit parity of preceding bits
6Stop 0
7Park
Not driven by the host. Must be read as “1” by the target because of
the pull-up
Table 223. ACK response (3 bits)
Bit Name Description
0..2 ACK
001: FAULT
010: WAIT
100: OK
Table 224. DATA transfer (33 bits)
Bit Name Description
0..31 WDATA or RDATA Write or Read data
32 Parity Single parity of the 32 data bits
