Universal synchronous asynchronous receiver transmitter (USART) RM0008

797/1128 DocID13902 Rev 15

Figure 286. Break detection in LIN mode (11-bit break length - LBDL bit is set)

Case 1: break signal not long enough => break discarded, LBD is not set

Break frame

RX line

Break State machine

Capture Strobe

Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9

Idle Idle

Read Samples

Bit0

0000000001

Bit10

Break frame

RX line

Break State machine

Capture Strobe

Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9

Idle Idle

Read Samples

Bit0

0000000000

B10

Case 2: break signal just long enough => break detected, LBD is set

LBD

Break frame

RX line

Break State machine

Capture Strobe

Bit1 Bit2 Bit3 Bit4 Bit5 Bit6 Bit7 Bit8 Bit9

Idle Idle

Read Samples

Bit0

0000000000

Bit10

Case 3: break signal long enough => break detected, LBD is set

wait delimiter

LBD

delimiter is immediate
