Page 14 | Stellar
®
AutoTarper Owner’s Manual
When installing the rear mounting tubes on non-Stellar products, please note the following
dimensional guidelines:
24.00
11.00
center of rear axle to
front of rear mounting tube
center of left rear mounting tube bolt hole to
center of right rear mounting tube bolt hole
top of truck frame to
top of rear mounting tube
39.00
Note: Installation on non-Stellar products
