Step 28: Install hydraulic kit.
Install the hydraulic kit components as shown:
ID QTYPART DESCRIPTION
26
21
21
21
6
24
25
23
25
26
21
21
21
21
3 C0927 CAP SCR 0.31-18X2.25 HHGR5 2
4 0339
CAP SCR 0.25-20X2.50 HHGR5 2
5 0522
WASHER 0.31 LOCK 2
6 0340
WASHER 0.25 USS FLAT 10
21
C4662 HOSE CLAMP #72 SS 4
23 8622
CLAMP HOSE/TUBE AG-2 16
24
C1005 CAP SCR 0.38-16X2.50 HHGR8 8
25 0346
WASHER 0.38 USS FLAT 16
26 0347
NUT 0.38-16 HHGR5 NYLOC 8
27 0438
CAP SCR 0.25-20X2.25 HHGR5 4
3
5
6
4
6
27
28
6
28 0333 NUT 0.25-20 HHGR5 NYLOC 4
