AutoTarper Owner’s Manual
Step 21: Install arm lift cylinder.
Step 22: Install lower arm weldment.
Install the arm lift cylinder as shown (both sides):
Install the lower arm weldment as shown (both sides):
23
25
28
23
25
27
28
ID QTYPART DESCRIPTION
23 79406 CYLINDER 2.00X30.00 2
25
13400CR PIN TEAR DROP 1.00X4.38 2
27 0343
WASHER 0.31 USS FLAT 2
28 0420
CAP SCR 0.31-18X0.75 HHGR5 2
26
12
13
12
13
27
28
18
26
12
13
12
13
18
25
27
28
ID QTYPART DESCRIPTION
12 0867 MACHY WASHER 1.00ID 14GA 7
13 0110
SNAP RING 1.00 ID 7200-100 6
18 c1592 ZERK 1/8 NPT STRAIGHT 4
25
13400CR PIN TEAR DROP 1.00X4.38 6
26
79728ZP PIN 1.00X2.75 SR 2
27 0343
WASHER 0.31 USS FLAT 6
28 0420
CAP SCR 0.31-18X0.75 HHGR5 6
