AutoTarper Owner’s Manual | Page 19
Step 17: Bolt frame rail bracket to frame rail.
Secure the frame rail bracket to the frame rail using the ve (5) bolts as shown (both sides):
14
13
15
14
13
14
15
ID QTYPART DESCRIPTION
13 C1026 CAP SCR 0.63-11X2.50 HHGR8 10
14
C5902 WASHER 0.63 SAE FLAT YELLOW GR8 20
15 24868
NUT 0.63-11 HHGR8 NYLOC 10
Step 16: Drill holes into frame rail.
Drill ve (5) 11/16” holes through the frame rail bracket and frame rail as shown (both
sides):
88
11/16"
