AutoTarper Owner’s Manual
Step 12: Bolt slide weldments to bumper.
Bolt the slide weldment to the bumper as shown (both sides):
21
19
19
20
21
19
19
20
ID QTYPART DESCRIPTION
19 0352 WASHER 0.50 USS FLAT 8
20 0501
CAP SCR 0.50-13X2.00 HHGR5 4
21
C6106 NUT 0.50-13 HHGR5 NYLOC 4
