Stellar
®
AutoTarper Owner’s Manual | Page 51
Rotate the arms down to lay tarp roll on top of container. Move the gantry down slightly to
tension the tarp at the front.
Rotate the arms to the rear of the load within 1 foot of the top of the container. Move the
slide to position the roll on the top of rear corner of the container.
Do not stop arms abruptly, but feather the hydraulic valve to stop slowly.
Tarping Step 4: Rotate arms and slide back.
Tarping Step 5: Lower tarp.
