AutoTarper Owner’s Manual
Step 15: Weld side mount tube.
Weld the side mount tube to the slide and rail bracket as shown (both sides):
8
5
8
5
ID QTYPART DESCRIPTION
579855 GUSSET 0.25X3.38X10.00 W/HOLE 2
847209
BRKT FENDER KP60 2
.25
.25
.25
.25
