Page 48 | Stellar
®
AutoTarper Owner’s Manual
It is recommended that the operator rephase arms and slides daily before each use of the
AutoTarper.
Rephasing is accomplished by synchronizing oil ow through the ow divider/combiner
valves when fully retracting or extending each pair of cylinders:
To rephase arm cylinders:
With the AutoTarper arms resting on the gantry (arm cylinders fully retracted), hold the Arm
control handle down (Uncover-Rephase) for 5 seconds.
To rephase slide cylinders:
With the slides in the maximum back position (slide cylinders fully retracted), hold the Slide
control handle down (Back-Rephase) for 5 seconds.
Cylinder Rephase Procedure
