Stonex R25/R25LR Total Station - User Manual 37
• T_Offset is the length offset;
• L_Offset is the cross offset;
• H_Offset is the height.
In “Mode” row, define the period during which the offset is to apply. Two modes are available:
o Reset: The offset values are reset to 0 after the point is saved;
o Forever: The offset values are applied to all further measurements.
The item F1[RESET] sets eccentricity to zero.
Selecting F4[ENT] the corrected values are calculated. The corrected angle and distances are displayed once a valid
distance measurement has been triggered.
Target Set: change between three target types:
• Prism: Distance measurements with prisms;
• Sheet: Distance measurements with sheets;
• NoPrism: Distance measurements without prisms.
After type selection, press “F4” to return previous page and simultaneously save setting result.
The target type can be changed directly from the measure menu, pressing the {SHIFT} key.
Delete Last Record: this function deletes the last recorded data block. This can be either a measurement block or
a code block.
NOTE: Deleting, the last record is not reversible! Only records which were recorded in "Surveying" or in "Measuring"
can be deleted.
Height Transfer: this function determines the height of the instrument from measurements to a maximum of 5
known target points, in two faces.
