Side view - right
A Electrical power switch
B Compressed air inlet
C Electrical power connection
Rear view
A Water inlet
B Regulation valve for disc cooling
C Regulation valve for OP flush
A AUX connector
B Beacon connection
C Service sockets
Control panel
See Control panel functions ►21.
4 Transport and storage
If, at any time after the installation, you have to move the unit or place it in storage, there is a number
of guidelines we recommend that you follow.
• Package the unit securely before transportation.
Insufficient packaging could cause damage to the unit and will void the warranty. Contact
Struers Service.
• Struers recommends that all original packaging and fittings are kept for future use.
12 AbraPol-30
4 Transport and storage
