• Additive for recirculation unit
• Exhaust system
10.2 Packaging specifications
X: 114 cm/44.9"
Y: 116 cm/45.7"
Z: 175 cm/68.9"
Weight Up to 500 kg/0.5 t. The weight is stated on
the crate.
The weight depends on the configuration of
the machine.
10.3 Location
Distance from the floor to the following units
Emergency stop 107 cm/42.1"
Front panel 130 cm/51.2"
Display 141 cm/55.5"
Cover handle (open/closed) Open: 137 cm/53.9"
Closed: 106 cm/41.7"
Illumination
Make sure that the machine is adequately lit up. A minimum of 300 Lumen is recommended to
illuminate the controls and other work areas.
Ambient conditions
Operating environment Surrounding
temperature
5-40°C/40-105°F
Humidity Max. 90 % RH non-
condensing
68 AbraPol-30
10 Pre-installation checklist
