CAUTION
Risk of hand to arm vibration during manual preparation.
Prolonged exposure to vibration may cause discomfort, joint damage or even
neurological damage.
Handling vibration during operation
Manual preparation may cause vibrations in hand and arm. To lower the vibration, decrease the
pressure or use a vibration-reducing glove.
• Limit grinding/polishing operations to a maximum of 10 minutes. Wait for 5 minutes before
continuing grinding/polishing.
5.6 Compressed air supply
For specifications, see Technical data - AbraPol-30 ►54
1. Connect the compressed air hose to the compressed air inlet on the machine.
2. Connect the air hose to the compressed air supply.
3. Secure the connections with hose clamps.
5.7 Connecting to an exhaust system
For specifications, see Technical data - AbraPol-30 ►54.
Struers recommends that the machine is connected to an exhaust system.
1. Connect a 52 mm pipe to the exhaust outlet on the machine.
2. Connect the other end of the pipe to the exhaust system.
5.8 Connecting to the water supply
If the machine is used without a recirculation unit, it must be connected directly to the main water
supply in these cases:
• if an OP-pump is mounted
• if disc cooling is required
Water from the main water supply Water from the recirculation unit (option)
Procedure
1. Connect the pressure hose to the water inlet hose on the back of the machine:
16 AbraPol-30
5 Installation
