Water outlet - drain
Water outlet specifications
Hose supplied 2 m/6.5"with an outlet under the machine
Water outlet diameter 50 mm/2"
10.12 Compressed air
Specifications
Pressure 6 - 9.9 bar/87 - 143 psi
Air consumption, approx. 30 l/min/8gpm at atmospheric pressure
Air quality Class-3, as specified in ISO 8573-1
10.13 Exhaust (option)
Recommended
Minimum capacity: 50 m
3
/h (1750 ft
3
/h) at 0 mm (0") water
gauge.
An exhaust system is required when working with alcohol-
based suspensions or lubricants.
10.14 Recirculation unit (option)
The use of a Struers recirculation unit is recommended.
The recirculation unit includes
• a recirculation pump
• a recirculation tank
• a filter bag
• a disposable tank liner
• a GEKA coupling for connection to the machine hose
• a power cable for connection to the machine
74 AbraPol-30
10 Pre-installation checklist
