9 Technical data
9.1 Technical data - AbraPol-30
Subject Specifications
Safety standards See the Declaration of Conformity
Preparation discs Diameter 300 mm (12”), 350 mm (14”)
Speed 40-600 rpm, in steps of 10
Power consumption 2.2 kW (2.9 Hp)
Specimen holder Speed 50-300 rpm, in steps of 10
Direction Clockwise/Counter-clockwise
Force 50-700 N (11-150 lbf)
Motor - Power consumption 0.55 kW (0.75 Hp)
Pump unit Level 0-20
Number of pumps 1-6
Operating environment Surrounding temperature 5-40°C (41-104°F)
Humidity < 85 % RH non-condensing
Storage and transport
conditions
Surrounding temperature -20 – 60°C (-4 – 140°F)
Humidity < 85 % RH non-condensing
Water supply Water pressure 1-4 bar (14.5-58 psi)
Water flow Min. 10/min (2.6 gpm)
Compressed air Pressure 6-9.9 bar (87-143 psi)
Flow 30 l/min (8 gpm)
Recommended quality ISO 8573-1, class 6.8.4
Exhaust system Dimensions Diameter: 52 mm (2")
Recommended capacity at 0
mm (0") water gauge
50 m
3
/h (1750 ft
3
/h)
Power supply Power, nominal load 3 kW
Number of phases 3 (3L+PE)
Output, main motor 2.2 kW
Voltage/frequency Max. load
3 x 200-240 V/50-60 Hz 20 A
3 x 380-480 V/50-60 Hz 11 A
