1. From the Main menu select Configuration > Options > Bottle configuration.
1 to 6 configuration options are shown depending on the number of pump units
and pumps that are installed.
You can configure positions 5 and 6 for OP pumps.
2. Press F1 to select the Pump configuration screen.
3. Select the pump type you wish to configure: DP pump or OP pump (with water
connection).
4. Press F4 to return to the Bottle configuration screen.
5. Select the first bottle.
6. Select Suspension, Lubricant or None (if no dosing bottle is connected).
7. If a bottle with diamond suspension is connected to pump 1, select Suspension.
8. Select Type.
9. Select the Select suspension type menu.
10. Select the correct type and grain size of the suspension you are using.
11. Repeat the procedure for all of the following pumps/bottles until all bottles are
configured correctly.
12. Press Back until the Main menu screen is shown.
6.3.4 User defined consumables
From the User defined consumables menu you can access the following screens:
• Surface configuration
• Suspension configuration
• Lubricant configuration
User surface configuration
1. From the Configuration menu, select User surface configuration.
2. In the Surface name column you can select an item. You can rename or delete
this item.
3. To return to the Configuration menu, press Back
