Filling the recirculation tank
1. Before you fill the tank, make sure that there is
room under the machine for the recirculation
unit to slide in easily. If this is not the case, use
the adjustable feet to adjust the height of the
machine.
2. Make sure that the recirculation unit is placed
correctly under the machine:
– The wheels of the unit must be in line with
the sides of the compartment so that you
can move the unit into position without
having to wiggle it from side to side.
– The pump must be placed on the left hand
side and close to the rear end of the
recirculation unit.
Note
To prevent corrosion, Struers recommends using a Struers additive in the cooling
water. For more information, see the additive container.
3. Line the tank with a clean plastic liner.
CAUTION
The recirculation tank is very heavy when it is full.
Note
Do not overfill the tank.
Avoid spilling when you move the tank.
4. Fill up the tank with cooling fluid. Make sure that
the water/additive ratio is correct.
18 AbraPol-30
5 Installation
