Procedure
1. Carefully separate the tubes at the couplings.
2. Press the two tabs on the pump and remove the
pump from the axle.
3. Press the two tabs on the pump and remove the
bottom cover of the pump.
Hint
If needed, use a flat-headed
screwdriver to press gently on the
tabs.
A Couplings
B Silicon tubes
C Tabs
4. Remove the three rollers.
5. Remove the Novoprene tube.
6. Fit the new tube into the housing and press it
firmly into place.
46 AbraPol-30
7 Maintenance and service - AbraPol-30
