Struers AbraPol-30 - Page 59

16303050 C
AKR/AKR
C
A1, Printed Circuit Board
Multi Purpose PCB
Y1,
Upper air in
Y3,
Upper air out fast
Y4,
Reduced lower air
RS232
X4, Connector
for LAN
USB
X2, Auxilliary
Connector
X5, Connector
for Service
Solenoid Valves
for air
CAN
Connector for
Struers Memory
Module
A4, Frequency Converter
- 750W
3x SPI
Stock Removal
linear potentiometer
50 mm stroke
Analog input
12 bit res.
Connector for
Initial prog.
Connector for
Debug / Test
CPU, V850SJ3, 1M flash, 60K ram
SRAM, 256Kx16
NVRAM, serial 32Kx8
Display Controler, S1D13706
Real time clock
Heart beat Indicatot
PCB-version detection
Buzzer
6x voltage supervision, 10bits ADC
P
U
P
U
2x analog input
12 bit res.
Air Pressure
Transmitters
RP1
BP1 BP2
(X15)(X16)
(X22) (X21)
(X20)
(X11)
(X11)
(X8)
Safe Torque
Off function
Safe Torque
Off function
A5, Frequency Converter
- 2,2kW
Input (X14)
(X16)
24V Output
(X3)
4x outputs
+24V
Reed switch,
Head in top position
(X3)
+155°C Thermal switch, NC
Y2,
Upper air out
(X3)
B1
X3, Connector for
Beacon
(X3)
(X3)
(X5) HL1,
Light
24Vdc output
(X4)
C
B
A
#2
(DP)
#3
(DP)
#4
(DP)
#5 #6
(DP or OP)
(Optional Dosing modules)
Y6
6x outputs
+/-24Vdc
Solenoid Valves
for water
(combined unit)
3x outputs
+24V
OPS flush
Disc cooling
Grinding water
Connectors for Dosing modules
#1
(DP)
X30
(X7)
X31 X32 X33 X34 X35
Gear
116:28
Specimen mover head,
50-300 rpm, CW/CCW
3~
550W
4-pole
M1, AC-gearmotor
for specimen mover
Working light
24V-S4
1x outputs
1x outputs
1x outputs
1x outputs
(sink driver)
Y7,
Release Pressure
(X5)
+155°C Thermal protection
Belt gearing
5:1
Disc
40-600 RPM, CW/CCW
3~
2,2kW
4-pole
M2, AC-motor
for disc
24V-S2
12V PWM
Epson
S1D13706
24V-1 (unswitched)
6x4 Matrix (6 out / 4 in)
BR1,
Turn/Push button
SB1
Touch Pad
Parallel
TFT Color Display,
320x240 dots
with white LED
backlight
5V, 2+1 dig.input
Powersupply
24Vdc / 5A
A2
Display
A3
(X19)
(X12)
(X9)
(X23)
(X1)
(X2)
(X2)
24V-1
24V-S2
3x200-240V or
3x380-480V,
50/60 Hz
Main Supply in
Mains
switch
X1
QS1
3p
A2 A1
24V-S4
S1,
Emergency
Stop
(X14) Input
Safety relay status
RESET
KS1,
Safety relay
24V-1
GND 24V
Z1, Filter
F4-F6
F1-F3
K1, Contactor
24V-S3
X20, Connector for
Recirkulation pump
1x outputs
(X4)
(X4) 1x outputs
YS1,
Work Zone Guard
Interlock
FT1
24V-S2
24V-2
S1-1 S1-2
(X4)
Y10,
Drain shift
(Optional)
(X14) Input
E-STOP status
S1-3
Rev.B: 2017.05.01 AKR
Changes to the safety system
Rev.C: 2020.05.07 CZO
HQ1 removed
Size
Scale
CAGE Code
DWG NO
Rev
Sheet
of
telephone: +45 44 600 800
Struers ApS
16303050
Thursday, May 07, 2020
1 1
A2
Pederstrupvej 84
DK-2750 Ballerup
Denmark
AbraPol-30, Block Diagram
Size
Scale
CAGE Code
DWG NO
Rev
Sheet
of
telephone: +45 44 600 800
Struers ApS
16303050
Thursday, May 07, 2020
1 1
A2
Pederstrupvej 84
DK-2750 Ballerup
Denmark
AbraPol-30, Block Diagram
Size
Scale
CAGE Code
DWG NO
Rev
Sheet
of
telephone: +45 44 600 800
Struers ApS
16303050
Thursday, May 07, 2020
1 1
A2
Pederstrupvej 84
DK-2750 Ballerup
Denmark
AbraPol-30, Block Diagram
9 Technical data
AbraPol-30 59
