Stryker EPIC II Service Manual

Return To Table of Contents
www.stryker.com 2030-809-002 REV D 115
EPIC II
®
Domestic, EPIC II
®
PLUS, and ZOOM
®
Common Litter Components - 2032-231-010
(Reference Only)
Litter Assembly
B 0003-074-000 Hex Hd. Cap Screw 2
C 0003-078-000 Hex Hd. Cap Screw 4
D 0003-214-000 Hex Hd. Cap Screw 8
E 0003-347-000 Hex Hd. Cap Screw 4
F 0004-032-000 Soc. Hd. Cap Screw 4
G 0004-085-000 Soc. Hd. Cap Screw 2
H 0004-101-000 Soc. Hd. Cap Screw 1
J 0005-019-000 Carriage Bolt 18
K 0005-024-000 Carriage Bolt 4
L 0005-023-000 Carriage Bolt 3
M 0007-058-000 Truss Hd. Torx 6
N 0007-063-000 Truss Hd. Torx 20
P 0007-065-000 Truss Hd. Torx 16
S 0011-053-000 Washer 10
T 0011-063-000 Washer 37
U 0011-158-000 Washer 22
W 0013-010-000 Ext. Tooth Lock Washer 17
X 0013-018-000 Ext. Tooth Lock Washer 14
Y 0013-032-000 Ext. Tooth Lock Washer 2
Z 0014-007-000 Washer 2
AB 0016-003-000 Nylock Nut 4
AC 0016-028-000 Nylock Nut 21
AD 0016-035-000 Nylock Nut 8
AE 0016-102-000 Nylock Nut 7
AF 0003-224-000 Hex Washer Hd. Screw 16
AH 0025-142-000 Rivet 37
AJ 0025-147-000 Rivet 4
AK 0026-012-000 Roll Pin 2
AL 0026-168-000 Spiral Pin 2
AN 0027-017-000 Cotter Pin 2
AP 0028-120-000 Ext. Retaining Ring 3
AR 0030-045-000 Strain Relief 3
AS 0030-036-000 Grommet 4
AT 0030-047-000 Right Angle Strain Relief 2
AU 0030-052-000 Snap Bushing 4
AX 0038-111-000 Cable Tie 10
AY 0038-151-000 Cable Tie 17
AZ 0038-382-000 Compression Spring 2
BA 0044-029-000 Black Foam Tape 1
BB 0044-032-000 1” Wide Poly Tape 50”
BC 0052-104-000 Cable Clamp 1
BD 0052-759-000 Flange Bearing 2
BE 0052-762-000 Nyliner Bushing 2
BF 0058-056-000 Black Edge Trim 1.5’
BG 0058-076-000 Drive Fastener 2
BH 0059-133-000 Push-Mount Wire Clip 1
BJ 0059-135-000 Push-Mount Wire Clip 7
BK 0059-157-000 Power Supply 1
BL 3001-300-007 Jack Screw 4
BM 0059-743-000 Wire Harness Clip 2
BN 0059-751-000 Locking Circuit Bd. Supt. 6
BP 0059-767-000 Cable Clamp 2
BR 0059-773-000 Push Spacer 4
BS 0059-774-000 Locking PCB Support 1
BT 0081-268-000 Flange Bearing 15
BU 0715-001-333 Rel. Valve Stop Sleeve 18
BW 0988-002-708 Shock Caution Label 1
BX 2020-03 4-758 Rest-Calf Section 2
BY 2025-031-062 Pot. Actuator Link 1
BZ 2025-031-088 Ground Jumper 4
CA 3002-300-870 Ground Strap 8
CB 2025-032-068 Flange Bearing 2
CD 2025-032-076 Ball Bearing 2
CE 2025-032-077 Fowler Actuator Link 2
CF 2025-032-082 Hydraulic Dampener 2
CG 2025-032-084 Fowler Screw Up Stop 1
CH 2025-032-085 Fowler Screw Down Stop 1
CJ 2025-032-086 Thrust Washer 5
CK 2025-032-087 Roller Cage Bearing 2
CL 2025-231-061 Pot. Timing Clamp 1
CM 2025-231-088 Fowler Link 1
CN 2025-231-090 Torque Tube Pivot Brg. 2
CP 2025-231-099 Bed Extender Rel. Lever 2
CR 2025-231-112 Bed Extender Pin Lock 2
CS 2025-232-089 Fowler Nut Box 1
CT 2025-232-090 Fowler Ball Screw 1
CU 2035-031-048 Short CPR Cable 1
CW 2035-031-049 Long CPR Cable 1
CX 2032-031-050 Scale Frame Weldment 1
CY 2035-031-051 Torque Tube Weldment 1
CZ 2035-031-054 Iso. Frame Weldment 1
DA 2035-031-055 Head End Crosstube 1
DB 2035-031-057 Bed Extender Weldment 1
DC 2035-031-064 Torq. Tube Ret. Brkt., Lt. 1
DD 2035-031-065 Torq. Tube Ret. Brkt., Rt. 1
DE 2035-031-066 Torque Block Channel 2
DF 2035-031-094 Foot Support Cover 1
DG 2032-031-097 Seat Section Skin 1
DH 2035-031-100 Wire Channel Cover 2
DJ 2035-031-115 Roller Bracket Cover, Rt. 1
DK 2035-031-116 Roller Bracket Cover, Lt. 1
DL 2035-031-126 Protective Sleeve 2
DM 2035-031-127 Nylon Stop 2
DN 2035-031-801 Inlet/Fuse Cable 1
DP 2035-049-801 Footboard/CPU Cable 1
DR 2035-032-052 Gatch Trigger Weldment 1
DS 2035-032-054 CPR Rel. Wldmt. Brkt. 1
DT 2035-032-072 CPR Release Pivot Brkt. 1
DU 2035-032-077 Gatch Actuator Link 2
DW 2035-032-079 Act. Box Swch. Brk. 2
DX 2035-032-084 Gatch Screw Up Stop 1
DY 2035-032-085 Gatch Screw Down Stop 1
DZ 2035-032-088 Act. Box Motor Mtg. Brkt. 2
EA 2035-032-090 Gatch Ball Screw Ass’y 1
Item Part No Part Name Qty. Item Part No Part Name Qty.
