Stryker EPIC II Service Manual

Return To Table of Contents
116 2030-809-002 REV D www.stryker.com
Litter Assembly
EB 2035-032-096 Ball Screw Cover 1
EC 2035-032-801 Gatch Limit Switch Cable 1
ED 2035-032-802 Fowler/CPU Jmpr Cable 1
EE 2035-032-803 Fowler Pot. Cable 1
EF 2035-032-804 Fuse/PCB Cable 1
EH 2032-033-050 Fowler Frame Weldment 1
EJ 2035-033-062 CPR Release Slide Brkt. 2
EK 2035-033-063 Fowler Skin 1
EL 2032-034-050 Thigh Section Weldment 1
EM 2032-035-150 Foot Section Weldment 1
EP 2035-231-085 Seat Section Cover 2
ER 2035-233-064 Quick Drop Rel. Brkt., Lt. 1
ES 2035-233-065 Quick Drop Rel. Brkt., Rt. 1
ET 2035-400-565 Siderail Guide Bracket 2
EU 2035-432-075 Actuator Box Cover Ass’y 1
EW 2040-090-100 500 Lb. Label 2
EX 3000-300-058 Switch Plunger 2
EY 3000-300-099 Modified Bushing 9
EZ 3000-300-115 Standoff 4
FA 3000-300-349 Head/Footboard Post Cap 4
FB 3000-300-353 Roller 4
FC 3000-300-442 Fowler Drive Grommet 16
FD 3000-300-455 CPR Isolation Bushing 4
FE 3000-300-456 CPR Isolator 2
FF 3000-300-461 CPR Decoupler 2
FG 3000-300-462 CPR Wing 2
FH 3000-300-464 CPR Engagement Spring 4
FJ 3000-300-473 Clevis Pin 2
FK 3000-300-477 CPR Conduit Stud 6
FL 3000-300-478 CPR Conduit Clamp 6
FM 3001-200-228 Mounting Standoff 2
FN 3001-300-008 Thigh Bumper 4
FP 3001-300-099 Flange Bearing 12
FR 3001-300-603 CPR Release Label 2
FS 3001-300-663 Velcro Strip 10
FT 3001-300-877 Siderail Extension Cable 1
FW 5000-030-366 Fowler Nut Adapter 1
FX 5010-080-007 Power Supply Gd. Cable 1
FY 8800-380-000 Neoprene Sponge 1.5’
FZ 8815-001-100 Wire Mount Clip 2
GA 0011-310-000 Washer 1
GB 0011-002-000 Washer 5
GC 0007-052-000 Truss Hd. Torx 4
GD 0013-038-000 Ext. Tooth Lock Washer 2
GE 2025-231-089 Fowler Litter Link 1
GF 0059-194-000 Split Ferrite 1
HA 0003-347-000 Hex Hd. Cap Screw 8
HB 0004-338-000 Flanged But. Hd. Screw 4
HC 0005-029-000 Rd. Hd. Sq. Neck Bolt 4
HD 0007-058-000 Truss Hd. Torx 1
HE 0011-539-000 Washer 32
Item Part No Part Name Qty. Item Part No Part Name Qty.
HF 0011-063-000 Washer 8
HG 0013-010-000 Ext. Tooth Lock Washer 1
HH 0013-032-000 Ext. Tooth Lock Washer 4
HJ 0016-006-000 Kep Nut 9
HK 0016-035-000 Nylock Nut 8
HL 0025-050-000 Rivet 24
HP 0059-106-000 Strain Relief 1
HR 2030-031-801 Foot Pot. Exten. Cable 1
HU 2030-031-802 Head Pot. Exten. Cable 1
HW 2030-031-803 Head Lift Motor Ext. 1
HX 2040-031-056 Foley Bag Hanger 6
HY 3001-300-004 Spacer 8
JD 0016-014-000 Nylock Nut 1
JH 0034-021-000 Cord Clamp 1
JR 3000-200-224 Idle Gear Thrust Washer 6
NG 3002-407-950 CPU 1
YA 3003-300-033 Mattress Retainer 4
YC 2035-032-805 Cable CPU/Power Supply 1
YD 2035-020-85 Siderail Limit Switch
Bypass Cable 2
YE 0003-005-000 Hex Head cap Screw 1
YF 2030-031-148 Gatch Damper Cover 1
YG 0921-001-252 Serial Number Date Tag 1
EPIC II
®
Domestic, EPIC II
®
PLUS, and ZOOM
®
Common Litter Components - 2032-231-010 (Continued)
(Reference Only)
HS 2030-331-052 Head End Header Wldmt. 1
HT 2030-331-053 Foot End Header Wldmt. 1
HS 2040-031-252 Head End Header Wldmt. 1
HT 2040-031-253 Foot End Header Wldmt. 1
ZOOM
®
/EPIC II
®
/EPIC II
®
PLUS - 2040-032-020
Standard Height Option
Item Part No Part Name Qty.
Item Part No Part Name Qty.
ZOOM
®
/EPIC II
®
/EPIC II PLUS
®
- 2040-032-021
Enhanced Height Option
