Stryker EPIC II Service Manual

Return To Table of Contents
www.stryker.com 2030-809-002 REV D 117
Litter Assembly
EPIC II
®
PLUS/ZOOM
®
Litter
Components - 2040-132-011
Item Part No. Part Name Qty.
KA 0007-058-000 Truss Hd. Torx 1
KB 0013-010-000 Ext. Tooth Lock Washer 2
KC 0016-028-000 Nylock Nut 1
KD 2040-231-807 Bed CPU Cable 1
KE 3000-300-002 Plastic Clip Nut 3
KF 2040-031-100 Manual Push Label 1
KG 0059-194-000 Split Ferrite 3
KH 0059-738-000 Hole Plug 2
EPIC II
®
Litter Domestic
Components - 2030-032-015
Item Part No. Part Name Qty.
NA 0059-179-000 Circuit Breaker 2
ND 2030-231-125 Specification Label 1
NE 2035-300-705 Motor Sub-assembly 2
NF 0039-254-000 Power Cord 1
NK 0037-246-000 Square Hole Plug 1
EPIC II
®
PLUS Litter Components - 2030-232-015
Item Part No. Part Name Qty.
NA 0059-179-000 Circuit Breaker 2
KJ 2030-231-125 Specification Label 1
NE 2035-300-705 Motor Sub-Assembly 2
Smart TV Option - 2035-130-207
Item Part No. Part Name Qty.
UC 3003-039-800 STV Option Board Ass’y 1
2030-034-010 Foot Prop Option
Item Part No. Part Name Qty.
HE 0011-539-000 Washer 4
AA 0014-008-000 Washer 4
AM 0027-015-000 Cotter Pin 4
EN 2035-035-096 Foot Prop Rod 1
BF 0058-056-000 Black Edge Trim 6”
Japan Option - 2031-200-000 (not shown)
Item Part No. Part Name Qty.
2031-200-002 Power Inlet Cable 1
0059-208-000 Circuit Breaker 2
0059-140-000 Capacitor 2
2031-200-001 Specification Label 1
2035-300-705 Fowler Drive Assembly 2
0039-254-000 Power Cord 1
0059-207-000 Capacitor 2
High-Sounding Beeper Option - 2030-030-251
Item Part No. Part Name Qty.
PA 3001-508-870 High-Sound Beeper Cable 1
Low-Sounding Beeper Option - 2030-030-151
Item Part No. Part Name Qty.
PA 3001-508-870 Low-Sound Beeper Cable 1
No Scale or Bed Exit Options - 2030-030-100
Item Part No. Part Name Qty.
2030-135-010 Footboard, No Scale/BE 1
OF 3001-300-511 “Imitation” Load Cell 4
GG 3000-300-353 Roller 4
Scale Option Only - 2030-140-125
Item Part No. Part Name Qty.
OA 0013-032-000 Ext. Tooth Lock Washer 4
2030-135-013 Footboard, Scale Option 1
OC 2030-317-805 Load Cell Cable, Head 2
OD 2030-317-804 Load Cell Cable, Foot 2
OE 3001-300-007 M/F Screw 8
OF 3002-307-057 Load Cell 4
GG 3002-300-353 Roller 4
Bed Exit Option - 2030-140-175
Item Part No. Part Name Qty.
OA 0013-032-000 Ext. Tooth Lock Washer 4
2030-135-012 Ft. Bd., Bed Exit Option 1
OC 2030-317-805 Load Cell Cable, Head 2
OD 2030-317-804 Load Cell Cable, Foot 2
OE 3001-300-007 M/F Screw 8
OF 3002-307-057 Load Cell 4
GG 3002-300-353 Roller 4
Scale & Bed Exit Options - 2030-140-150
Item Part No. Part Name Qty.
OA 0013-032-000 Ext. Tooth Lock Washer 4
2030-015-014 Ft. Bd., Bed Exit with
Scale Option 1
OC 2030-317-805 Load Cell Cable, Head 2
OD 2030-317-804 Load Cell Cable, Foot 2
OE 3001-300-007 M/F Screw 8
OF 3002-307-057 Load Cell 4
GG 3002-300-353 Roller 4
