Cradle Operation
115 EN
Setting Up the Cradle
Warning To reduce the risk of electrical shock, do not use the
cradle within a 1.5-meter radius of the patient.
Warning To reduce the risk of electrical shock, use only the
supplied DC adapter and hospital-grade AC power
cord with the cradle.
Warning To reduce the risk of electrical shock, do not connect
the cradle to an extension cord. Do not connect the
cradle to a multiple-socket outlet to which other
medical devices are connected.
1. Position the cradle on a flat, level surface near a hospital-grade
outlet.
2. Connect the DC power adapter to the hospital-grade power
cable.
3. Connect the DC adapter cable to the DC-input port on the rear of
the cradle.
4. Connect the hospital-grade power cable to a hospital-grade AC
outlet. The Power LED on the cradle will shine green, indicating
the cradle is connected to a power source.
Charging the Tablet and Tablet Battery
Warning To reduce the risk of electrical shock, never touch any
part of the cradle and the patient simultaneously.
To charge a battery that is still connected to the tablet:
1. Insert the tablet into the tablet-charging dock as shown in Figure
2 below.
Note The Battery Charge LED on the cradle will not illuminate
while an entire tablet is docked in the cradle. Instead, the
Battery LED on the tablet itself will shine orange while the
battery charges and will shine green once the battery has
been fully charged.
Cradle Operation
