Setting Up the Sidne™ System
25 EN
Setting Up the Transmitter
Warning To maintain sterility in the surgical field, set up the
transmitter and headpiece prior to scrubbing for
surgery.
1. Ensure the batteries are installed in the transmitter.
• Release the battery door and insert two AA batteries, observing
polarity.
• Close the battery door.
2. Power on the transmitter by holding the power button for three
continuous seconds.
3. Select an operating frequency for the transmitter.
Note This frequency should match the frequency chosen for the
receiver in order for the headset to communicate properly.
For more information on selecting an operating frequency,
consult 3000 Series Professional UHF Wireless Systems,
the user manual packaged with the headset.
• Press the set button on the transmitter two times. “Edit”
appears on the LCD window.
• Press the up or down arrows to select the desired frequency.
• Hold the set button until the LCD reads “STORED.”
• Slide the sliding control cover over the buttons to protect
against inadvertent button selections.
4. Select the same operating frequency for the receiver.
• Press the set button on the receiver two times.
• Press the up or down arrows to select the same frequency
selected on the transmitter.
• Hold the set button until the LCD reads “STORED.”
• Press the down arrow until “QUIT” appears on the LCD.
• Press the set button until the status bar shows on the LCD.
5. Clip the transmitter to an article of clothing away from the hands
and operating site.
Setting Up the Headpiece
Warning To maintain sterility in the surgical field, set up the
transmitter and headpiece prior to scrubbing for
surgery.
1. Connect the headpiece connector to the audio-input jack on the
transmitter.
