18 EN
Setting Up the Console
Warning When Sidne™ is interconnected with other electrical
equipment, leakage currents may be additive. Ensure
all systems are installed according to the requirements
of IEC 60601-1-1.
Warning Ensure that the power switch is set to 120 V or 240 V as
appropriate prior to plugging in the device. User injury
and or product damage may result in the use of an
incorrect power setting.
To set up the console, make the following connections:
1. Connect the AC power (see Figure 9).
• Plug in the female end of the AC power cord to the AC power
supply input on the rear console panel.
• Plug in the male end of the AC power cord to a hospital-grade
electrical outlet.
Caution Use only hospital-grade power cables, such as the
cable provided with the Sidne™ system. Using other
cables may result in increased RF emissions or
decreased system immunity.
2. Connect the operating-room devices that will be controlled by
Sidne™ (see
Figure 9).
• Connect the square end of a device cable to the device port on
the operating-room device.
• Connect the rectangular end of the device cable to one of the
eight device ports on the rear console panel.
3. Connect any external audio output (if desired) (see Figure 9).
• Connect external speakers to the external speaker port on the
rear console panel.
Note The Sidne™ console is equipped with internal speakers
that provide audio feedback. Connecting external speakers
will enhance audio feedback messages, but is not
necessary.
• Connect audio output for recording devices, such as a SDC , to
the appropriate voice-output port (9 for VCR; 10 for SDC) on
the rear console panel if desired.
4. Connect any video inputs.
Setting Up the Sidne™ System
