CAMSHAFT
MECHANICAL
Front
14) Install the crankshaft pulley. <Ref. to C: INSPECTION
ME(DOHC TURBO)-467 INSTALLATION, Crank-
shaft Pulley.> essa ry
.
15) Install the V-belt. <Ref. to ME(D0HC TURBO)-
44, INSTALLATION, V-belt.>
Limit:
1)
Measure the bend, and repair or replace if nec-
0.020
mm
(0.0008
in)
Center, rear
2)
Check the journal for damage and wear.
place
if
faulty.
Re-
I
37.946-37.9635 mm 29.946
-
29.963 mm
(1.4939- 1.4946 in) (1.1790- 1.1796 in)
I
Standard
I
4) Measurement of the camshaft journal
oil
clear-
ance:
(1)
Clean the bearing caps and camshaft jour-
nals.
(2)
Place the camshafts on the cylinder head.
(Without installing the valve rocker.)
(3)
Place a plastigauge across each of the cam-
shaft jounals.
(4) Gradually tighten the cap in at least
two
stages in alphabetical sequence shown in the
figure, and then tighten
to
specified torque.
20
N-m
(2.0
kgf-m,
14.5
ff-lb)
Tightening torque:
I
U
U
S2M1233A
I
CAUTION:
Do
not turn the
camshaft.
ME(
DOH
C
TU
R
BO)-62
