CYLINDER BLOCK
MECHANICAL
#1, #3, #5
#2, #4
Unit: mm (in)
Standard
0.03 (0.0012)
undersize
0.05 (0.0020)
undersize
59.992
- 60.008
(2.361 9
- 2.3625)
Journal
O.D.
I
59.992 - 60.008
(2.3619
- 2.3625)
47.984
- 48.000
(1.8891
- 1.8898)
0.25 (0.0098)
undersize
Bearing size
(Thickness at cen-
ter)
1.998
- 2.01 1
(0.0787
- 0.0792)
2.000
- 2.01 3 1.492-1.510
(0.0787
- 0.0793) (0.0587 - 0.0591)
59.962
- 59.978
(2.3607
- 2.361 3)
2.01 7
- 2.020
(0.0794
- 0.0795)
Journal
O.D.
Bearing size
(Thickness at cen-
ter)
59.962
- 59.978
(2.3607
- 2.361 3)
47.954
- 47.970
(1.8879
- 1.8886)
2.019
- 2.022 1.510- 1.513
(0.0795
- 0.0796) (0.0594 - 0.0596)
59.942
- 59.958
(2.3599
- 2.3605)
2.027
- 2.030
(0.0798
- 0.0799)
Journal O.D.
Bearing size
(Thickness at cen-
ter)
59.942
- 59.958
(2.3599
- 2.3605)
2.029
- 2.032
(0.0799
- 0.0800)
47.934 - 47.950
(1.8872
- 1.8878)
1.520
- 1.523
(0.0598
- 0.0600)
O.D.: Outer Diameter
4) Measure the thrust clearance of crankshaft at
center bearing.
If the clearance exceeds the limit,
replace the bearing.
Crankshaft thrust clearance:
Standard
Limit
0.030 - 0.115 mm (0.0012 - 0.0045 in)
0.25 mm
(0.0098 in)
59.742 - 59.758
(2.3520
- 2.3527)
59.742
- 59.758
(2.3520
- 2.3527)
Journal
O.D.
Bearing size
(Thickness at cen-
ter)
2.127-2.130 2.129
- 2.132
(0.0837
- 0.0839) (0.0838 - 0.0839)
EN0341 I
5) Inspect individual crankshaft bearings for signs
of flaking, seizure, melting, and wear.
47.734 - 47.750
(1.8793
- 1.8799)
1.620
- 1.623
(0.0638
- 0.0639)
6) Measure the oil clearance on each crankshaft
bearing by means of plastigauge.
If the measure-
ment is not within the specification, replace the de-
fective bearing with an undersize one, and replace
or recondition the crankshaft as necessary.
Standard
I Unit: mm fin) I
0.01 0 - 0.030 (0.0004 -
0.001 2)
I Limit I 0.040 (0.0016) I
