INTAKE MANIFOLD
FUEL INJECTION (FUEL SYSTEMS)
15) Connect the connector
to
the purge control
so-
lenoid valve.
16)
Connect the connector to the tumble generator
valve sensor.
\/
/
EN0800
17)
Connect the connector to the tumble generator
valve actuator.
\J
EN0799
18)
Connect the connector to the fuel injector.
I
II
EN0798
19) Install the throttle body to the intake manifold.
NOTE:
Replace gasket with a new one.
Tightening torque:
22
N-m
(2.2
kgf-m,
15.9
fl-lb)
EN0785
20) Connect the connector
to
the throttle position
sensor
(A),
idle air control solenoid valve
(B)
and
pressure sensor (C).
21) Connect the engine harness with clip
(D) to the
intake manifold.
(
D)
S2M2249A
(D,
FU(D0HC TURBO)-27
