User Manual 10 Appendix II: LCD Operation
93
Do not press ESC to exit this interface, otherwise the test results will
be cleared and you need to do the test again.
For each test, the values of
frequency / voltage and the
trip times will be visualized
as well as the current
values of the frequency
and voltage measured by
the inverter.
Press / to scroll pages
and press ESC to exit.
The thresholds (Imp.) are
compliant with standard
CEI 0-21 and the actual
values (Ril.) are for your
reference only.
Pass.: The inverter will
restore the normally used
settings and automatically
reconnect to the grid.
Fail: The inverter will report
the error 105. The inverter
cannot reconnect to the
network until the test faults
are cleared.
Imp. / Ril.
Tempo (s)
Risult.
50.50/49.99
0.10/0.10
Pass.
Risult.
253.0/230.0
3.00/2.96
Risult.
Risult.
Risult.
Risult.
Risult.
Risult.
81>.S1 81>.S2
Valo. (Hz)
Imp. / Ril.
81<.S1
Imp. / Ril.
81<.S2
Imp. / Ril.
Tempo (s)
Valo. (Hz)
Tempo (s)
Valo. (Hz)
Tempo (s)
Valo. (Hz)
49.50/49.99
0.10/0.10
47.50/49.99
0.10/0.10
51.50/49.99
0.10/0.10
Pass.
Pass. Pass.
59.S1
Imp. / Ril.
Tempo (s)
Valo. (V)
Pass.
264.5/230.0
0.10/0.10
59.S2
Imp. / Ril.
Tempo (s)
Valo. (V)
Pass.
195.5/230.0
0.40/0.40
27.S1
Imp. / Ril.
Tempo (s)
Valo. (V)
Pass.
92.0/230.0
0.20/0.20
27.S2
Imp. / Ril.
Tempo (s)
Valo. (V)
Pass.
If the auto test fails, Press ENT to confirm
“Canc. Guasto Test” and clear the test faults.
Iniziare Autotest
Auto Test
Canc. Guasto Test
If an external command aimed at changing the frequency protection
thresholds is sent to the inverter during the testing process, the test
results will be invalid. You should restart the system and re-do the auto
test.
