GENERAL INFORMATION 1-9
*SERVICE DATA
*These service data are subject to change without notice.
POWERHEAD
Recommended operating range
r/min 4700 – 5300
Idle speed
700 ± 50 (in-gear: approx.700)
r/min
5200 – 5800
*Cylinder compression
1300 – 1600 (13 – 16, 185 – 228)
kPa (kg/cm
2
. psi)
*Cylinder compression max.
difference between any other
cylinders
200 (2.0, 28)
kPa (kg/cm
2
. psi)
*Engine oil pressure
{Oil temp. at 60°C (140°F)}
420 – 490 (4.2 – 4.9, 60 – 70) at 3000 r/min
kPa (kg/cm
2
. psi)
Engine oil
Engine oil amounts
L (US/Imp. qt)
Thermostat operating
temperature
58 – 62 (136 – 144)
°C (°F)
API classification SE, SF, SG, SH, SJ
Viscosity rating SAE 10W-40
4.5 (4.8/4.0) : Oil change only
4.8 (5.1/4.2) : Oil filter change
* Figures shown are guidelines only, not absolute service limits.
Item Unit
Data
DF60T DF70(W)T/70WTH
CYLINDER HEAD / CAMSHAFT
0.05 (0.002)
mm (in)
Limit
Cam height
mm (in)
38.061–38.221 (1.4985–1.5048)
37.631–37.791 (1.4815–1.4878)
Cylinder head distortion
0.10 (0.004)
mm (in)
Limit
Intake manifold seating
faces distortion
STD
Limit
mm (in)
37.961 (1.4945)
37.531 (1.4776)
IN
mm (in)
38.059–38.219 (1.4984–1.5047) 37.629–37.789 (1.4815–1.4878)
STD
Limit
mm (in)
37.959 (1.4944)
37.529 (1.4775)
EX
0.050 – 0.091 (0.0020 – 0.0036)
mm (in)
Camshaft journal oil
clearance
STD
Limit
0.150 (0.0059)
mm (in)
Camshaft
holder inside
diameter
Top
mm (in)
STD 45.000 – 45.016 (1.7717 – 1.7723)
0.10 (0.004)
mm (in)
Limit
Camshaft runout
Rocker arm shaft to
rocker arm clearance
0.012 – 0.045 (0.0005 – 0.0018)mm (in)
STD
0.090 (0.0035)
mm (in)
Limit
Rocker arm inside
diameter
16.000 – 16.018 (0.6299 – 0.6306)mm (in)
STD
Rocker arm shaft
outside diameter
15.973 – 15.988 (0.6289 – 0.6294)mm (in)
STD
Rocker arm shaft
runout
0.12 (0.005)
mm (in)
Limit
2nd
mm (in)
STD
44.800 – 44.816 (1.7638 – 1.7644)
3rd
mm (in)
STD
44.600 – 44.616 (1.7559 – 1.7565)
4th
mm (in)STD 44.400 – 44.416 (1.7480 – 1.7487)
Bottom
mm (in)STD 44.200 – 44.216 (1.7402 – 1.7408)
Camshaft
journal outside
diameter
Top
mm (in)STD 44.925 – 44.950 (1.7687 – 1.7697)
2nd
mm (in)STD 44.725 – 44.750 (1.7608 – 1.7618)
3rd
mm (in)STD 44.525 – 44.550 (1.7530 – 1.7539)
4th
mm (in)STD 44.325 – 44.350 (1.7451 – 1.7461)
Bottom
mm (in)STD 44.125 – 44.150 (1.7372 – 1.7382)
