ENGINE CONTROL SYSTEM 3-3
SYSTEM STRUCTURE 2
Fuel tank
Primer bulb
Low pressure
fuel filter
Low pressure
fuel pump
Evaporation
hose
Fuel
pressure
regulator
High
pressure
fuel
pump
Fuel
vapor
separator
Delivery pipe
CMP
sensor
Ignition
coil
Ex-mani.
temp. sensor
*O
2
sensor
Exhaust
manifold
Spark plug
Alternator
(Battery charge coil)
By-pass air screw
CTP switch
IAT sensor
Rectifier &
regulator
Battery
Ignition
switch
ECM main
relay
Engine control module
Neutral
switch
Silencer
cover
Throttle
body
IAC
valve
Intake
manifold
Cylinder
temp.
sensor
CKP
sensor
Oil pressure
switch
Fuel
injector
Breather
hose
* : O2 Sensor must be installed when performing “O2 feedback operation” only.
High pressure
fuel filter
MAP
sensor
