POWER UNIT 6-5
INSTALLATION
Installation is reverse order of removal with the special attention
to the following steps.
!
Do not re-use the gaskets once removed. Always use
new gaskets.
• Install the two dowel pins 1 and the gaskets 2.
• Apply the thread lock to the two bolts as shown.
"99000-32050: THREAD LOCK “1342”
• Tighten the eight bolts and the three nuts according to the
numerical order as shown.
# Intake manifold bolt/nut: 25 N
.
m (2.5 kg-m, 18.0 lb-ft)
• Install the fuel injector and the delivery pipe.
CHECKING
Check hose routing. (See the page 10-8 to 10-12.)
Check wire routing. (See the page 10-2 to 10-7.)
Check for fuel leakage and water leakage.
