6-4 POWER UNIT
17. Remove the two bolts.
18. Disconnect the wire from the high pressure fuel pump.
19. Pull out the oil level gauge 1.
20. Remove the bolt and the gauge guide 2.
21. Disconnect the evaporation hose from the fuel vapor sepa-
rator.
22. Remove the eight bolts and the three nuts.
23. Remove the intake manifold assy.
To Next Page
