6-6 POWER UNIT
POWER UNIT
REMOVAL
Before removing the power unit:
• Drain the engine oil.
• Remove the intake manifold assy. (See the page 6-2.)
1. Remove the electric parts holder. (See the page 4-17.)
2. Remove the two bolts and the rectifier & regulator.
3. Remove the screw and the cylinder temperature sensor.
4. Disconnect the spark plug caps from the spark plug.
5. Disconnect the wires from the ignition coils.
6. Remove the four bolts and the ignition coils.
To Next Page
