POWER UNIT 6-7
7. Remove the flywheel. (See the page 3-52.)
$ 09930-48720: Flywheel holder
09930-39411: Flywheel remover
09930-39420: Flywheel remover bolt
8. Remove the battery charge coil. (See the page 4-4.)
9. Remove the CKP sensor and the CMP sensor. (See the page
3-52.)
10. Disconnect the MAP sensor wire.
11. Remove the starter motor. (See the page 4-10.)
12. Remove the four bolts and the starter motor bracket.
13. Remove the eight bolts, the four nuts and the exhaust mani-
fold.
14. Disconnect the water inspection hose 1.
15. Disconnect the water hose from the water pressure valve
cover 2.
