FUEL SYSTEM 5-17
INSPECTION
Fuel connector
Inspect the fuel connector and the connector plug. If leakage, de-
terioration or other damage is found, replace the connector and/
or the plug.
Fuel primer bulb
Inspect the fuel primer bulb. If crack, leakage or deterioration is
found, replace the bulb.
If the check valve function is defective, replace the bulb.
Fuel tank
Inspect the fuel tank. If crack, leakage or deterioration is found,
replace the tank.
If water or other contamination is found, drain and clean the
tank.
Tank cap
Check that the fuel tank vent opens and relieves internal tank
pressure properly.
If vent is suspect, replace the tank cap.
1
2
1
2
1. Connector 2. Connector plug
Fuel hose
Inspect the fuel hoses. If cut, crack, leakage, abrasion, tear or
deterioration is found, replace the hoses.
