4-10 ELECTRICAL
STARTER MOTOR
REMOVAL
Before removing starter motor:
• Disconnect battery cables from battery.
1. Remove the screw and the flywheel cover.
2. Remove the breather hose and the evaporation hose.
3. Remove the bolt, the fastening band and the silencer cover.
4. Disconnect the lead wire connectors from the IAT sensor,
the IAC valve and the CTP switch.
5. Disconnect the throttle linkage rod.
6. Remove the flame arrester and the seal rubber.
7. Remove the six silencer / throttle body securing bolts.
To Next Page
