POWER UNIT 6-31
14. Remove the piston pin from the piston and the conrod us-
ing the tool and an arbor press as shown.
$ 09910-38211: Piston pin remover & installer
NOTE:
Reassemble each piston, piston pin and conrod with their origi-
nal combination and position.
Piston
Mark “O”
Hole
Press
1
3
4
5
6
7
2
1. Driver handle
2. Piston
3.piston pin
4. Piston pin guide
5. Base cap
6. Base
7. Support
