MID UNIT 7-13
9. Remove the driveshaft housing with the oil pan from the
steering bracket.
10. Remove the bolts and the upper mount cover 1.
11. Remove the upper mount assy 2.
12. Remove the lower mount assy 1.
13. Remove the six bolts and the engine holder.
14. Remove the two bolts 1 and the oil strainer 2.
To Next Page
