PERIODIC MAINTENANCE 2-13
INDEX
mark
INDEX
mark
12. Rotate the crankshaft 2 or 4 rotations to remove looseness.
13. Make sure that the PUNCH mark “1” on the cam pulley aligns
with the INDEX mark on the cylinder head block when the
PUNCH mark on the timing pulley aligns with the INDEX mark
on the cylinder block.
14. Lightly push the tensioner toward the belt, then tighten the
two bolts.
15. Install the following parts.
• Starter motor bracket
• Battery charge coil (See page 4-5.)
• Flywheel (See page 3-52.)
• Spark plugs
• Flywheel cover
To Next Page
