Issue 2: Sep 99 TMSL 097-44018-26
Page 145
COMMAND CODE: SET-TH-MSG
PURPOSE
SET THRESHOLD MESSAGE
This command changes the persistence delay for DCIM cards and the nonswitching message delay,
switching message delay, and the holdover message delay for the shelf.
INPUT FORMAT
SET-TH-MSG:[<tid>]:<aid>:<ctag>::[<durmsg>],[<nswmsg>],
[<swmsg>],[<hldovrmsg>];
The parameter values in the table below are as follows:
a = 1–2 or ALL
aid parameter value meaning
DCIM-a durmsg 0–2000 persistence delay: amount of time (ms) from an SSM change at an in-
put until the new SSM is sent to the MIS card (in 100 ms steps)
nswmsg (null) (not applicable)
swmsg (null) (not applicable)
hldovrmsg (null) (not applicable)
SHELF durmsg (null) (not applicable)
nswmsg 0–2000 nonswitching message delay: amount of time (ms) from a signal
quality SSM change (following the persistence delay and which does
not require a switch or rearrangement) at an input until the new SSM is
sent to the timing output cards (in 100 ms steps)
swmsg 0–2000 switching message delay: amount of time (ms) from a signal quality
SSM change (following the persistence delay and which requires a
switch or rearrangement) at an input until the new SSM is sent to the
timing output cards (in 100 ms steps)
hldovrmsg 0–3600 holdover message delay: amount of time (s) from when the clocks go
into holdover until the holdover SSM is sent to the timing output cards
(in 1 s steps)
