Symmetricom TimeProvider 500 series Reference Guide

TMSL 097-44018-26 Issue 2: Sep 99
Page 34
COMMAND CODE: ED-EQPT (Contd)
INPUT FORMAT (Contd)
aid parameter value meaning
GTI-a framing CAS channel associated signaling
CAS4 channel associated signaling with cyclic redundancy check 4
CRC4 common channel signaling with cyclic redundancy check 4
D4 D4 framing
ESF ESF framing
FAS common channel signaling
troublecode ALW AIS is sent on all outputs when card has major alarm
INH all outputs are squelched when card has major alarm
portseverity (null) (not applicable)
osc1 QTZ oscillator 1 (OSC A) is quartz clock
RB oscillator 1 (OSC A) is rubidium clock
osc2 QTZ oscillator 2 (OSC B) is quartz clock
RB oscillator 2 (OSC B) is rubidium clock
integration 1 see Table E
2 see Table E
3 see Table E
4 see Table E
clklevel (null) (not applicable)
alarmlead
signaltype ANALOG output signal is analog
DIGITAL output signal is digital
MCA framing (null) (not applicable)
troublecode
portseverity MJ a port failure causes a major alarm
MN a port failure causes a minor alarm
osc1 (null) (not applicable)
osc2
integration
clklevel
alarmlead ALW a protection switch activates the shelf alarm lead
INH a protection switch does not activate the shelf alarm lead
signaltype (null) (not applicable)
