XLi Time & Frequency System 153
XLi-man, Issue 8, 6/17/2008, Rev. H
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
• Second Serial Talker or T1 / E1 (87-8047)
Command Line
To display a summary of the XLi option bay information, enter the following command:
F118
The XLi responds:
F118<S>B<N><S><OC><CR><LF>
where:
For example, enter:
F118<CR>
XLi responds:
F118 B1 GPS RECEIVER
F118 B2 N.1 FREQUENCY SYNTHESIZER
F118 B3 NOT RECOGNIZED
F118 B4 GPS RECEIVER
F118 B5 NOT RECOGNIZED
F118 B6 NOT RECOGNIZED
F118 B7 NOT RECOGNIZED
F118 B8 NOT RECOGNIZED
F118 B9 NOT RECOGNIZED
F118 B10 NOT RECOGNIZED
F = ASCII character F.
118 = function number.
<S> = ASCII space character one or more.
B = ASCII letter to denote Option Bay number follows
<N> = Option Bay Number, 1 through 10.
<OC> = Option Card Name:
• GPS RECEIVER or
• N.1 FREQ SYNTHESIZER or
• FTM III MONITOR or
• HAVE QUICK SYNC or
• HAVE QUICK OUT or
• PTTI BCD Output or
• Parallel BCD Output or
• NOT RECOGNIZED (if no Smart Option Card is
installed)
<CR> = carriage return.
<LF> = line feed.
